Η Yamaha MG-06 ειναι 6κάναλη αναλογική κονσόλα-  2 Mic / 6 Line Inputs Max. 2 Mic / 6 Line Inputs (2 mono + 2 stereo) / 1 Stereo Bus, D-PRE προενισχυτές μικροφώνων, XLR balanced outputs,PAD switch στις εισόδους mono, +48V phantom power.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Features

• 6-Channel Mixing Console
• Max. 2 Mic / 6 Line Inputs (2 mono + 2 stereo)
• 1 Stereo Bus
• “D-PRE” mic preamps with an inverted Darlington circuit
• XLR balanced outputs
• PAD switch on mono inputs
• +48V phantom power
• Metal chassis

Specifications

6-channel mixer

• channels 1-2:
  • mono mic/line inputs (XLR and 1/4" TRS)
  • switchable 26 dB pad
• channels 3/4 and 5/6:
  • stereo line inputs (1/4" TS)
• all microphone inputs:
  • D-PRE Class A microphone preamps
  • phantom power (+48 volts)
  • switchable high-pass filter (80 Hz, 12 dB/octave)
• 2-band EQ on chs 1-2 — high: 10,000 Hz (shelving) and low: 100 Hz (shelving)
• peak lights on chs 1-2

General features

• LED output meter with peak indicator
• rotary volume controls on each channel
• headphone outputs
• metal chassis
• Dimensions(W×H×D): 149 mm x 62 mm x 202 mm
• Net Weight: 0.9 kg
