Το Astell&Kern Kann Max ειναι ενα φορητο player (DAP), με 32bit/768kHz dsd dac, δεκτη Bluetooth 5.0 Qualcomm aptX και MQA playback δυνατοτητα.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

The KANN series is adored by audiophiles all over the world for its performance that focuses on ultra-high output and clear sound.
KANN ULTRA, the 5th product in the KANN series, continues the success of the KANN series by providing the highest output of any Astell&Kern player, the inclusion of Triple Output Sound, and an optimized processor and UI/UX to make it even easier to enjoy clear sound performance.

With four Gain Modes that provides up to 16Vrms of desktop Hi-Fi level output and sound, and ES9039MPRO Dual DAC chips, KANN ULTRA perfectly powers many of today's headphones with high resolution. A separate Pre/Line Out allow users to enjoy the sound with a variety of different devices.

Features

• Triple Output Mode Featuring Separately Configured Circuit and Amplifier Designs
• HEADPHONE OUT / PRE-OUT / LINE OUT
• Next-generation Octa-Core processors with significant high-performance improvements
• Supports 4 preset gain settings with ultra-high output up to 16Vrms (Headphone Out)
• Equipped with ES9039MPRO Dual DACs
• Features Digital Audio Remaster (DAR) technology
• Supports playback up to 32bit/768kHz, Native DSD512
• Features Astell&Kern's unique TERATON ALPHA technology
• Battery 8,400 mAh (up to 11 hours of playback)

Specifications

• Model KANN ULTRA
• Body Color Astro Gray
• Body Material Aluminum
• Display 5.5inch HD 1080 x 1920 touch screen
• Supported Audio Formats WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF, MQA
• Sample Rate PCM : 8kHz ~ 768kHz (8/16/24/32bits per Sample) , DSD Native: DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz),, Stereo  DSD256(1bit 11.2MHz), Stereo / DSD512(1bit 22.4MHz), Stereo
• Output Level
• HEADPHONE OUT
  • Low Gain Unbalanced 2Vrms, Balanced 4Vrms (Condition No Load)
  • Mid Gain Unbalanced 4Vrms, Balanced 8Vrms (Condition No Load)
  • High Gain Unbalanced 6Vrms, Balanced 12Vrms (Condition No Load)
  • Super Gain Unbalanced 8Vrms, Balanced 16Vrms (Condition No Load)
• LINE OUT
  • Unbalanced 2Vrms, Balanced 4Vrms (Condition No Load)
• CPU Octa-core
• DAC ES9039MPRO x2
• Decoding Support up to 32bit/768kHz Bit-to-Bit Playback
• Input USB Type-C input (for charging & PC & MAC)
• Outputs
  • HEADPHONE OUT 3.5mm(Unbalanced Out, Optical Out), 4.4mm (Balanced Out, only 5-pole supported)
  • PRE LINE OUT 3.5mm(Unbalanced Out), 4.4mm (Balanced Out, only 5-pole supported)
• Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz)
• Bluetooth V5.3 (A2DP, AVRCP, Qualcomm® aptX™-HD, LDAC, LHDC)
• Dimensions 3.24” (82.4mm)[W] x 5.55” (141.1mm)[H] x 0.96” (24.4mm)[D]
• Weight About 390g
• Feature Enhancements Firmware upgrade supported (OTA)
• Operating Temperature 0C ~ + 40C (32F~104F)
• Frequency Response
  • HEADPHONE OUT
  • ±0.006dB (Condition : 20Hz~20kHz) Unbalanced ? ±0.004dB (Condition : 20Hz~20kHz) Balanced
  • ±0.016dB (Condition : 20Hz~70kHz) Unbalanced ? ±0.020dB (Condition : 20Hz~70kHz) Balanced
  • PRE OUT
  • ±0.022dB (Condition : 20Hz~20kHz) Unbalanced ? ±0.023dB (Condition : 20Hz~20kHz) Balanced
  • ±0.023dB (Condition : 20Hz~70kHz) Unbalanced ? ±0.023dB (Condition : 20Hz~70kHz) Balanced
  • LINE OUT
  • ±0.002dB (Condition : 20Hz~20kHz) Unbalanced ? ±0.002dB (Condition : 20Hz~20kHz) Balanced
  • ±0.007dB (Condition : 20Hz~70kHz) Unbalanced ? ±0.006dB (Condition : 20Hz~70kHz) Balanced
• S/N
  • HEADPHONE OUT 115dB @ 1kHz, Unbalanced ? 119dB @ 1kHz, Balanced
  • PRE OUT 110dB @ 1kHz, Unbalanced ? 126dB @ 1kHz, Balanced
  • LINE OUT 110dB @ 1kHz, Unbalanced ? 125dB @ 1kHz, Balanced
• Crosstalk
  • HEADPHONE OUT 134dB @ 1kHz, Unbalanced ? 140dB @ 1kHz, Balanced
  • PRE OUT 128dB @ 1kHz, Unbalanced ? 128dB @ 1kHz, Balanced
  • LINE OUT 129dB @ 1kHz, Unbalanced ? 121dB @ 1kHz, Balanced
• THD+N
  • HEADPHONE OUT 0.0004% @ 1kHz, Unbalanced ? 0.0004% @ 1kHz, Balanced
  • PRE OUT 0.0012% @ 1kHz, Unbalanced ? 0.0005% @ 1kHz, Balanced
  • LINE OUT 0.0013% @ 1kHz, Unbalanced ? 0.0005% @ 1kHz, Balanced
• IMD SMPTE
  • HEADPHONE OUT 0.0006% 800Hz 10kHz (4:1) Unbalanced ?0.0006% 800Hz 10kHz (4:1) Balanced
  • PRE OUT 0.0006% 800Hz 10kHz (4:1) Unbalanced ?0.0006% 800Hz 10kHz (4:1) Balanced
  • LINE OUT 0.0006% 800Hz 10kHz (4:1) Unbalanced ?0.0006% 800Hz 10kHz (4:1) Balanced
• Output Impedance
  • HEADPHONE OUT Unbalanced Out 3.5mm (1ohm) ? Balanced Out 4.4mm (1.3ohm)
  • PRE OUT Unbalanced Out 3.5mm (3.5ohm) ? Balanced Out 4.4mm (5.7ohm)
  • LINE OUT Unbalanced Out 3.5mm (6.5ohm) ? Balanced Out 4.4mm (10.7ohm)
• Clock Jitter 25pS (Typ)
• Reference Clock Jitter 200 Femto Seconds
• Built-in Memory 128GB [NAND]
• External Memory microSD x1 (Max. 1TB)
• Capacity 8,400mAh 3.8V Li-Polymer
• Charge Time about 3.5hours (PD 3.0 Charger)
• Playback Time about 11hours (Standard: FLAC, 16bit, 44.1kHz, Vol.50, LCD Off, Low Gain)
• Supported OS Windows 8,10,11 (32/64bit) MAC OS X 10.7
