Το Luxman D-07X ειναι CD-SACD player και USB DSD DAC. MQA-CD decoding.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων, ανταλλαγων.

LUXMAN is proud to announce the launch of our new SACD/CD player, the D-07X.
The D-07X is our mid-priced D series SACD/CD player, requested for a long time and after a 3 year development period, it truly
displays the performance of our D-10X flagship model, with the latest circuitry with great performance.
Our original LxDTM-i drive mechanism transport block is securely mounted directly on the chassis, based on the traditional left side
mechanical layout, that realizes the ideal signal path, leaving ample space for the high-quality digital and analog circuitry. It achieves
signal reading accuracy close to that of the D-10X.

The D/A converter block uses high-end BD34301EKV DAC chips from ROHM’s “MUS-IC” series, which was a hot topic when
installed in the D-10X for the first time in dual mono configuration. The USB input supports up to 768kHz/32 bit PCM and 22.4MHz
DSD digital data signals. In addition, it features a decoder system that fully supports MQA playback from a PC and also MQA CDs,
of which more and more titles are being released.

The analog circuitry is equipped with fully balanced I/V conversion receiving the separate outputs of the DAC chips, operating in
monaural mode, and newly developed discrete buffer circuitry that doubles as an LPF stage, powerfully driving the next stage
components, achieving the dynamic sound quality inherited from our flagship model.
The housing has a distinctive design with a blasted white front panel and a hairline finish top panel that creates an elegant contrast.
The display is wider and overhangs to create a three-dimensional and dynamic appearance.
The D-07X has a drive mechanism that picks up high quality music signals from digital discs, digital circuitry that enables handling of
all digital sound sources and newly developed analog circuitry that enhances rich musical content. It is our latest digital media player,
delivering an inspiring listening experience, full of detail and expression.

Features
Disc drive mechanism
- Mechanism block is mounted onto the rigid side chassis to protect against vibration
- Left-side mechanical layout with asymmetric configuration for ideal signal path and space to mount high-quality analog circuitry
Digital circuitry
- MUS-IC series top end BD34301EKV DAC chips by ROHM in dual mono configuration
- USB input supports PCM data up to 768kHz / 32bit and DSD data up to 22.4MHz, S/PDIF input supports PCM signals of up to 192kHz / 24bit
- Full MQA decoding support, clearly indicated by three different colored LEDs. In addition, all CD formats are supported as well as USB and
S/PDIF input
- Equipped with a new ultra-low phase noise clock module with high accuracy and low jitter that reduces noise near the oscillation frequency
- Equipped with a 2-mode analog FIR filter that adjusts to the desired sound quality when playing SACD and DSD files
Analog circuitry
- Newly developed discrete buffer circuitry, fully balanced output configuration (4 amplifiers with the same configuration) that drives the
differential output of the high quality D/A converters operating in monaural mode
- A highly stable power supply features a large power transformer, independent regulators for each circuit and large-capacity
Design
- Fluorescent display shows various modes with zoom and dimmer functions
- Shielded chassis structure that blocks digital noise
- Gold-plated, 32mm pitch RCA terminals, compatible with high-performance line cables with large connectors and shielded,
high-quality Neutrik XLR terminals
- The cast-iron insulator feet feature a density gradient, protecting the most sensitive audio signals from unwanted vibrations
Others
- New control input/output terminals that link remote control signals between compatible devices and will expand support for remote operation
by other wireless devices in the future
- Equipped with a new trigger input/output terminals that enables power supply syncing between compatible products
- Comes with an aluminum remote control featuring numeric keypad with excellent operability (RD-29)
- High-quality music playback software, LUXMAN Audio player, is available forWindows and Mac on our website for free

Specifications

• Supported media 2-channel SACD, CD, MQA-CD
• USB input (PCM): 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz,
• Sampling frequency 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz (16, 24, 32bit)
• USB input (DSD): 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz (1bit)
• COAX/OPT input: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz (16, 20, 24bit)
• Analog output voltage PCM 2.4V, SACD/DSD 2.3V
• Output impedance Unbalanced 300Ω / Balanced 600Ω
• Frequency response CD 5Hz~20kHz(+0, -1.0dB), SACD 5Hz~38kHz(+0, -3.0dB), USB 5Hz~47kHz(+0, -3.0dB)
• Total harmonic distortion CD 0.0016%, SACD 0.0007%, USB 0.001%
• S/N ratio (IHF-A) CD 123dB, SACD 125dB, USB 122dB
• D/A converter ROHM BD34301EKV (Monaural mode) x 2
• Power consumption TBC
• Dimensions / weight 440(W)x132(H)x410(D)mm / 17kg
• Accessories Remote controller(RD-29), power cable
