Ο Marantz PM-12SE ειναι στερεοφωνικος, τηλεχειριζομενος δικαναλος ενισχυτης, ισχυος 2x100 wrms στα 8 ohm.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

New Premium Products from Marantz are always reason for the audiophile community to celebrate. And the new 12 Series Special Edition is no exception. Marantz Special Editions are the Marantz way to celebrate the love of music that run deep in the veins of Marantz Sound Masters and engineers, exhibited in the artistry and craftsmanship of those special components. With unwavering attention to detail, Marantz Special Editions produce unequaled Hi-Fi sound that exalts the mastery and emotion of music.
The PM-12SE circuitry offers the cleanest signal path through amplifier, which delivers 100W per channel into 8ohm speakers, or 200Wpc into 4ohm. And, its equipped high-quality nickel-plated copper input terminals, and high-purity copper speaker connections.

Key Features

• Engineered and extensively tuned by a team, drawing on more than 65 years of Marantz amplifier design knowledge
• Marantz high-resolution preamplifier stage with proprietary HDAM technology
• Switching power amplifier design derived from flagship PM-10 amplifier
• Generous output: 100W + 100W (into 8ohm), 200W + 200W (4ohm)
• Fully-discrete, two-stage design for signal purity, with separate power supplies for preamp and power amplifier sections to reduce interference
• Toroidal transformer dedicated to preamp for clarity and powerful sound
• Current feedback design with newly-developed wide-range circuitry
• HDAM® SA3 circuitry for clean signal and optimal dynamics
• MM/MC Phono input with new discrete Marantz Musical Premium Phono EQ circuit
• Thick nickel-plated copper independent input terminals for CD and Phono, plus Marantz-original high-quality/high-purity copper-plated speaker terminals
• Linear volume control with new electric volume system
• High-quality construction with double-layer chassis and solid aluminum front
• Purest Mode deactivates unused circuits for best audio performance
• High-grade, carefully selected audio parts: ultra-low leak current Schottky diodes, low noise complementary transistors, high-grade resistors, newly developed custom electrolytic capacitors, audio grade film capacitors and mica capacitors.

Specifications

Channels	2
Current Feedback Topology
Phono EQ: Standard / Marantz Musical / Marantz Musical Premium	/ /
HDAM version	SA3, SA2
Power Transformer: Toroidal / El	SMPS
High Grade Audio Components
Customised Components
Symmetric PCB Layout
Aluminium extrusion heat sink	(Separate)
Balance / Bass / Treble / Loudness	/ / /

Linear Drive Power Supply	(pre-amplifier stage)
Liniear volume control
BI-AMP and Multichannel option
Shottky diodes
Input buffer amp (all inputs / CD only)	/
System block shielding: copper / metal / none	/ /
Double Layer Bottom Plate
Low Noise OELD display

Audio Inputs	6
Phono Input: MM / MC	/
Audio Outputs	2
Power Amp Direct IN
Gold Plated Cinch
Speaker A / B
Speaker Terminals	Marantz SPKT-100+
Number of terminals	2
D-Bus
Floating Control Bus (3.5 mm mono jack x 2)
Headphone Out

Metal Front Panel
Power Consumption in W	130
Standby Consumption in W	0.2
Auto power off
Detachable Power Cable
Remote Control	RC005PMSA
System Remote Function
Maximum Dimensions (W x D x H) in mm	440 x 453 x 123
Weight in kg	15.3
Carton Maximum Dimensions (W x D x H) in mm	557 x 536 x 243
Carton Weight (inc. product) in kg	18.4
