Το Rotel RDD-1580 ειναι ενας ψηφιοαναλογικος μετατροπεας (dac) στα 24bit/192kHz.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Specifications

• Intermodulation Distortion (60Hz:7kHz, 4:1) <0.004%
• Input Sensitivity 0dBfs
• Input Impedance 75Ω
• Output Level Unbalanced (RCA): 2V, Balanced (XLR): 4V
• Output Impedance Unbalanced (RCA): 100Ω, Balanced (XLR): 200Ω
• Total Harmonic Distortion (THD) (20Hz–20kHz) <0.004%
• Frequency Response 10Hz - 95kHz ±3dB
• S/N Ratio (IHF "A" Weighted 128dB
• Decodable Front USB Formats MP3, WAV, WMA, Ogg Vorbis (up to 48kHz 16-bit)
• Coax/Optical Digital Input Signals LPCM (Up to 24-bit/192kHz)
• PC-USB USB Audio Class 1 (up to 24/96), USB Audio Class 2 (up to 24/192)
• Dimensions (W × H × D) 431 × 55 × 316mm
• Front Panel Height 1U / 43.7mm (1.75")
• Power Requirements 230V, 50Hz
• Power Consumption 25W
• Standby Power Consumption 0.5W
• Net Weight 5.1kg
• BTU Rating 26 BTU/h
