Ο Naim NAP-350 ειναι μονοφωνικος τελικος ενισχυτης, ισχυος 1x175wrms στα 8 ohms.

Εγγυηση αντιπροσωπειας. Δυνατοτητα ανταλλαγων και δοσεων.

The NAP 350 delivers high power with precision and speed. Our engineers have developed specific electronic circuits to give the New Classic products superior performance. The NAP 350 has a new high-current output stage that uses matched pairs of Statement's NA009 custom power transistors. Combined with our acclaimed DR technology, it guarantees a stable and low-noise power supply.

Key Points

• Can be used with legacy products via the legacy range of cables.
• Separate DR PSUs for power amplifier, including the XLR input stage.
• Eight NA009 Naim custom designed power transistors as developed for Statement (4 for the PSUs and 4 for the output stages). Each mounted on ceramic insulators for ultra low capacitive coupling.
• Newly developed output stage with double
• driver and double power transistor - improved sound quality and more power.
• New triple transistor constant current source (CCS)in delicate gain stage - uses a newly developed CCS for improved sound quality.
• Party-proof: new heatsink design responds to temperature fluctuation, keeping things cool.
• 0.5W standby power
• Using two internal power supplies; one is a high quality audiophile linear type, based on a large toroidal transformer. The other is a highly efficient SMPSU for 0.5W power consumption in standby during standby mode.
• Soft-start power up sequence, preventing the large toroidal transformers from tripping mains circuit breakers due to the large influx of voltage required.
• 3.5mm optical inter-product communications for synchronised system control, preventing ground loops. This facility offers LED brightness and power control.
• Eddy current divide situated between speaker output terminals for improved sound quality.
• Custom audiophile components such as polystyrene capacitors in filter circuits for low dielectric absorption.
• Through-hole components reducing microphonies picked up via the circuit board fluctuations.

Specifications

• Input signal for clipping :
  1.33 VRMS
• Crosstalk : NA (mono)
• Damping factor in 8Ω : 36.0000
• Product type : Amplifier
• THD+N : 0.006%
• Analogue inputs : 1 x 47kΩ True balanced via XLR, 1 x 34kΩ singled ended via legacy adaptor lead
• Power Output :  175 Watts 8Ω at 0.1% THD+N
• Cables provided :  Power-Line Lite,, 1 x XLR-XLR Balanced Audio Interconnect, Optical System Automation Cable
• Power consumption in standby mode (deep sleep) : < 0.5W
• Consumption in normal use : 24 W
• Depth : 31.75 cm / 12.5 in
• Height : 9.15 cm / 3.62 in
• Width : 43.2 cm / 17 in
• Weight : 16.5 kg / 36.38 lb
