Το Marantz Link 10n ειναι network player streamer, με ενσωματωμενο DSD DAC υψηλης ποιοτητας. Εισοδοι: 1x Phono MM, 1x Analog RCA, 1x Analog XLR, 1x Digital Coaxial, 2x Digital Optical, 1x USB-B, 1x Ethernet. Ασυρματη συνδεσιμοτητα: WiFi, Bluetooth. Εξοδοι (fixed): 1x Analog RCA, 1x Analog XLR, 1x Digital Coaxial, 1x Digital Optical, 1x HDMI ARC CEC. Εξοδοι Προενισχυσης (variable): 1x Analog RCA, 1x Analog Sub RCA, 1x Analog XLR.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων, ανταλλαγων.

Features

• Hi-Res audio support
• HEOS® Built-in
• Roon Ready
• Hi-Res Color New HD TFT Color Display
• Newest HDAM and MM circuits
• HDMI ARC out with CEC support
• 2.1 channel subwoofer output

General Audio Features

• Output Circuit New HDAM
• Power Transformer Toroidal
• Pre Amplifier Circuit New HDAM High Grade Full balanced
• Volume Electric (MUSES 72323) Variable gain
• Bass, Treble and Balance Control
• Type of Tone Controls Electric
• Headphone Circuit Discrete
• H/P Amp Gain Setting Yes (Low / Mid / High)
• H/P On.Off Setting H/P Off automatically, when in use
• DAC Circuit New MMM-Conversion
• Dither MMM-Stream (Dither 1, 2, Off)
• Noise Shaper MMM-Stream: Balanced, Natural, Dynamic Music, Dymanic Voice)
• Digital Filter MMM-Stream: Filter 1, 2 Selectable
• Jitter Reducer
• DAC Master Clock Design (USB-DAC)
• Asynchronous mode (for USB-B input)
• Isolator (for USB-B input) Yes (Complete Isolation System Duo)
• Fixed Analog Output (RCA) Cinch × 1 Thick nickel plated independent terminals
• Pre / Variable Audio Output (RCA) Cinch × 1 Thick nickel plated independent terminals
• Fixed Balanced XLR Output Yes (1 Pair)
• Pre/ Variable Balanced XLR Output Yes (1 Pair)
• RCA Input Cinch × 1 Thick nickel plated independent terminals
• Balanced XLR Input Yes (1 Pair)
• Phono input Yes (MM / MC)
• Marantz Musical Premium Phono EQ w/ Selectable MC impedance (3 position) Thick nickel plated independent terminals
• Optical input / output (Maximum Support) 2 / 1 (on/off switchable): 44.1 kHz - 192 kHz
• Coaxial input / output (Maximum Support) 1 / 1 (on/off switchable): 44.1 kHz - 192 kHz
• HDMI output (ARC)
• Headphone Output Φ6.3 ×1
• Subwoofer with LP filter adjustable

Audio Specifications

• Frequency Response PCM 2Hz–50kHz (-3dB)
• Harmonic distortion PCM 0.0004%
• S/N PCM 0.0004%
• Dynamic range PCM 0.0004%
• Line Output Level UNBALANCED : 2.0Vrms
• Line Output Level BALANCED : 4.0Vrms
• Headphone Output Level 130mW / 32 ohms
• Frequency Response (analog input) 5 Hz–100 kHz (+0dB/-3 dB)
• Harmonic distortion (analog input) 0.001% (20Hz–20kHz)
• S/N PHONO: MC 76dB, MM 88dB, BALANCED 122dB, LINE : 122dB
• Phono Input sensitivity: MM 8mV, MC 80mV
• Phono Input impedance MC:32 ohms, 100 ohms, 390 ohms
• Phono Input impedance MM:39 kohms
• Power Consumption 7W
• Less than 0.3W (at Standby)
• Less than 2W (at Network Control On: Bluetooth, Ethernet, Wi-Fi, USB)

Chassis Specifications

• Panel Color Black / Marantz Champagne
• Front (Center) Pane Aluminum
• Back-shell Aluminum
• Front panel illumination Yes (All sides, Dimmer)
• Side cover Aluminum (Thickness: Max 15.8mm)
• Rear Panel Triple layer Copper-plated
• Chassis Material Copper-plated
• Bottom Layer / Bottom plate Copper-plated
• Volume Knob Solid aluminum (Bearing construction)
• Input Selector Solid aluminum (Bearing construction)
• Foot Solid aluminum with Copper
• Unit (W × H × D mm) 440 × 192 × 472 (with antenna)
• Cabinet Size 440 × 192 × 422
• Net weight 33.3kg

Easy To Use Specifications

• App HEOS app
• Remote Controller 10 series universal Remote control
• Front Panel Display New HD TFT Color Display
• Display Language N: (English/ German/ French/ Italian/ Dutch/ Spanish/ Swedish/ Polish/ Russian)
• Dimmer for Front Display 20 steps
• Volume Display 0 –100 / 0.5 step (defalut)-infinity/-99.5dB - 0dB / 0.5 step switchable
• Voice Assistant: Apple Siri, Google Assistant
• External Amp Control with App (Use Remote Control Bus)
• Synchronously turn on amplifier and switch the input (Use Remote Control Bus)
• HDMI CEC
• Included: Remote Controller RC004PMND
• Included: Power Cord Yes (ALL region : Audio Grade : OFC)
• Included: Stereo RCA Cable ×1
• Included: Remote connector cable ×1
• Included: CoA card
