DIN Size

1 DIN

Detachable Faceplate

Yes

Key Illumination

Blue LED

Rotary Encoder & Control Knob

Yes

Dual Accent Key

Audio settings & Easy EQ

Back-up Memory

Radio presets

Attenuator with Smooth Volume Return

Yes

Touch Sensor Tone

Yes

Digital Clock (24H)

Yes

Clock display when power-off

default off

All-off Select (20/40/60 minutes)

Yes

Built-in Connector

Mitsumi, 16 pin

ISO connector

Yes, Mitsumi to ISO cable

USB interface x 1

Yes, (Front)

Firmware upgreadable

Yes

Display Type

Liquid Crystal Display (LCD)

Display Layout

13 Segments x 13 Digit

Vertical Aligment Liquid Crystal Display

Yes

Display Illumination

White (LED)

Dimmer Control

Manual / Set by Timer

Brightness control

0 - 31 steps

Demo Mode

Yes

Menu text in selectable language

English(default) / Spanish / French / Russian

Dress plate

Piano Black

Preset key finish

Piano Black

Escutcheon finish

Black Injection

Volume & operation knob or wheel

Piano black with chrome finished ring

Triangle Illumination

Red LED

Front terminals dust cover

Yes

Key illumination

Blue LED

Illuminated front USB port

Blue LED

Brightness Control (Key)

0 - 31 step

Dimmer Control (Key)

Manual / Set by Timer

Brightness zone concept

2 zone brightness control

Station Select

Manual / Preset

FM Reception

Yes

AM (MW/LW) Reception

Yes

Tuner Presets (FM/AM)

24 Presets (18FM / 6AM)

Preset memory w/o back-up power

Yes

Mixed preset memory (FM & AM)

6 presets

Up/Down Seek/Scan

Yes

Automatic Memory Entry (AME)

Yes

FM Stereo / Mono Selector

Yes

Radio Data System

Yes

Radio Text Plus

Yes

Traffic Information

Yes

Local search

Yes

AF Regional

Selectable: AF/AF Reg/OFF

Auto TP search

Yes

Enhanced Other Networks Function (EON)

Yes

Program Type Function (PTY)

Yes

MP3 files are playable

CD/USB

WMA (.wma) files are playable

CD/USB

WAV (.wav) files are playable

USB

FLAC files are playable

USB

CD-R/RW Compatible

Yes

MP3 Playback with ID3 Tag Display

Yes

WMA (Windows Media Audio) Playback

Yes

CD Text with special Character Support

English(default) / Spanish / French / Russian / Greek

D.A.C. processing

24bit

0 bit Mute

Yes

Random Function

DISC Random/Random OFF

Repeat Function

Track Repeat/All Repeat

USB terminal

Yes, Front with dust cover

USB Type

2.0 High speed

Kenwood Music Control App for Android

Yes, (with Android OS 4.1 ~ 7.0 )

MP3, WMA, WAV, FLAC playback

Yes

Repeat/Scan/Random search

Yes

Repeat / Random Play

Yes

Direct search

Yes

Resume play

Yes

Time code display

Yes

1A Charge Capability for Smartphone.

Yes

Maximum Output Power

50W x 4

MOSFET Power IC

Yes

Auxiliary Type

Mini-jack, front panel

Pre-out

1 RCA

Pre-out Output Level

2.5V

Preout Rear / Subwoofer Switchable

Yes

Subwoofer Reference Level Adj.

Yes

Tone Control / Easy EQ

3-Band, 8 Presets

Balance/Fader/Loudness Control

Yes

Bass Boost Circuit

Off/+1/+2/+3/+4/+5

Att.(-20dB) with smooth Volume Return

Yes

Parametric Equalizer + Presets

3-Bands Parametric Equalizer with 8 Presets.

Low-pass Filter

Yes

Speaker Size Control

Yes, Off / 5" or 4" / 6*9" or 6" / OEM

Kenwood Sound Reconstruction

Yes

Drive EQ

Yes

Front USB & AUX Input

Yes

OEM Wired Remote Control ready

Yes

DC-Cord

Mitsumi to ISO

Power Control (P.CON) wire

Yes

Amplifier pre-out

1 RCA: Rear/Subwoofer (selectable)

FM Antenna Input

JASO connector

FM range: 87.5Mhz - 108MHz (50Khz step)

Yes

FM Usable Sensitivity

0.71μV/75ohm (S/N 30dBf)

FM Quieting Sensitivity

2μV/75ohm (S/N 46dBf)

FM Frequency Response

30Hz ~ 15kHz (± 3dB)

FM Signal to noise ratio (Mono)

64dB

FM Stereo Separation (1kHz)

40dB

MW range: 531kHz - 1611kHz (9kHz step)

Yes

MW Usable Sensitivity

28.2μV

LW range: 153kHz - 279kHz (9kHz step)

Yes

LW Usable Sensitivity

50μV

MP3 Format

MPEG 1/2 Audio Layer 3-Files

WMA Format

in accordance with Windows Media Audio

WAV Format

RIFF waveform Audio Format (only for LinearPCM)

FLAC Format

FLAC files (up to 48kHz/16bit)

Laser Diode

GaAIAs

Digital Filter(D/A)

8 Times Over Sampling

Digital/Analogue Converter

16 Bit

Wow & Flutter

Below Measurable Limit

Frequency Response

20Hz ~ 20kHz (±1dB)

Total Harmonic Distortion

0.01% (1kHz)

Signal to Noise Ratio

92dB (1kHz)

Dynamic Range

88dB

Channel Separation

83dB

MP3 Decoder

Compliant with MPEG-1/2 Audio Layer-3

WMA Decoder

Compliant with Windows Media Audio

USB Version compatibility

USB 1.1/2.0 full speed

File System

FAT 32/16/12

Maximum Supply current

1000mA

D/A Converter

16 bit

MP3 Decode

Compliant with MPEG-1/2 Audio Layer-3

WMA Decode

Compliant with Windows Media Audio

WAV Decode

Linear - PCM Files

flac Decode

FLAC files up to 48kHz/16bit

Maximum Power

50W x 4

Output Power (DIN45324,+B=14.4v)

22W x 4

Output frequency band

20Hz ~ 20kHz

Preout Level

2500mV / 10kOhm,

Preout Impedance

≤ 600Ohm

Speaker Impedance

4Ohm ~ 8Ohm

AUX Frequency Response

20Hz ~ 20kHz (±1dB)

AUX Maximum Input Voltage

1000mV

AUX Input Impedance

30kOhm

Bass Tone Control

100Hz ±8dB

Middle Tone Control

1kHz ±8dB

Treble Tone Control

12.5kHz ±8dB

Low Pass Filter Frequency (Hz)

Through/85/120/160Hz

Subwoofer Level (dB)

-15 dB to +15dB

Release keys

2 pieces

Escutcheon

Yes

Installation Sleeve

Yes

DC cord (Mitsumi to ISO)

15 cm

Operating voltage

14.4V (10.5 ~ 16V Allowable)

Maximum Current Consumption

10A

Dark Current Consumption

Below 1mA

Dimensions (WxHxD)

182 x 53 x 155.5mm

Weight

1200 gr.

Operation Temperature Range

-10°C ~ 60°C

Instruction Manuals

Multi-language quick Guide
