Ο Marantz AV-7706 ειναι προενισχυτής AV home cinema 11.2 καναλιων. Υποστηριζει Dolby Atmos, DTS:X, Auro 3D, 8K60Hz, 4K120Hz, eARC, HDR, HDR+, HDR10, Dolby Vision, IMAX Enhanced, DSD, Flac, Apple AirPlay 2, Alexa, Google Assistant and Apple Siri. Streaming: Tidal, Spotify κλπ. Ασυρματη διασυνδεσιμοτητα μεσω Wi-Fi, Bluetooth, Heos. Ενσυρματη διασυνδεσιμοτητα μεσω USB, HDMI, RCA, Coaxial, Optical.

Εγγυηση αντιπροσωπειας. Δυνατοτητα δοσεων.

The AV7706 is made for home cinema enthusiasts who want everything, versatility, flexibility and musicality. The Pre-Amplifier expertly handles any kind of high-resolution stereo or multichannel audio format. Enjoy superb surround sound audio quality from the latest formats including Dolby Atmos, DTS:X, IMAX Enhanced and Auro-3D. The AV7706 enhances audio quality by delicately handling all signals via the Marantz's own current feedback HDAMs amplifier modules, before passing them to the high-quality 11.2 channel XLR or 11.2 RCA outputs and separate power amps.

Enjoy exquisite video performance thanks to the latest HDMI technologies such as 8K/60Hz pass-through or upscaling, various HDR format support including HDR10, HDR10+, Dolby Vision, Hybrid Log-Gamma (HLG) and Dynamic HDR, as well as the latest gaming technologies such as 4K/120Hz pass-through, Variable Refresh Rate (VRR) and Auto Low Latency Mode (ALLM).

Extensively tuned by world-renowned sound acousticians at the most state-of-the-art facilities, the new Marantz AV7706 leverages decades of experience in Hi-Fi to drive exceptional, audiophile-quality surround sound for all your entertainment.

Key Features

• Premium-performance AV pre-amplifier with 11.2 channel XLR pre-out for maximum home cinema flexibility and musical fidelity
• Featuring the most advanced three-dimensional audio formats: Dolby Atmos, Dolby Atmos Height Virtualization Technology, DTS:X and DTS Virtual:X, IMAX Enhanced and Auro-3D processing are all supported to allow you to listen to all of your favourite audio styles.
• Advanced 32-bit Conversion on All Channels: For optimum fidelity and the widest dynamic range with lowest distortion, the AV7706 features advanced reference-class 32-bit AKM D/A converters on all channels. This ensures consistent high fidelity and precise channel matching across all channels for the ultimate listening experience.
• Exclusive components elevate the Marantz sonic signature: Marantz proprietary HDAM circuit boards, Current Feedback circuitry, AKM AK4458 32-bit D/A converters, and Hybrid PLL Clock Jitter Reducer produce more detailed, dynamic sound.
• Audyssey MultEQ XT32 automatized setup and room acoustic correction with Dynamic Volume, Dynamic EQ, Sub EQ HT and Low Frequency Containment deliver a full-range balance, including deep bass with improved definition.
• 8K/60Hz and 4K/120Hz pass-through support for every entertainment need: With the latest technology in HDMI support, enjoy 8K quality video from your 8K source devices or with 8K upscaling from Full HD or 4K sources.
• HDMI eARC Object-Based Audio Support: eARC (Enhanced Audio Return Channel) supports the transmission of 3D audio from your TV with a single HDMI connection for the simplest setup.
• The greatest technology for home cinema: Support for the latest HDR formats including HDR10, HDR10+, HLG, Dolby Vision, 4:4:4 colour resolution and BT.2020, as well as Dynamic HDR provides exceptional picture quality for brightness, clarity and contrast.
• The Next Level in Gaming: Enjoy your gaming with 4K/120Hz pass-through, as well as Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM), which reduces or eliminates lag and frame tearing.
• HEOS Built-in: Almost unlimited music sources: Stream from music services like Spotify Free and Premium, Amazon Music HD, Tidal and more, or stream directly from smart devices via AirPlay 2 or Bluetooth
• Phono EQ Stage with HDAM: The HDAM component of the Marantz AV7706 outperforms op-amp solutions due to its high speed and maintains a clean audio signal for exceptional sound performance.
• Dual Subwoofer Outputs: Surround yourself with even, accurate bass. The AV7706 features two subwoofer outputs to smooth low frequencies and improve bass dispersion, avoiding peaks and audible dips. Connected subwoofers can be calibrated independently thanks to Audyssey Sub EQ HT technology for more seamless bass performance tailored to your room.

Specifications

DTS HD Master / DTS:X	/
DTS:X Pro
DTS Neo:X / DTS Neural:X	/
DTS Virtual:X
Dolby TrueHD / Dolby Atmos	/
Dolby ProLogic Il / Dolby Surround	/
Dolby Height Virtualization
Front Wide Speakers: Dolby / DTS
Auro 3D
IMAX Enhanced
MPEG-H
Multichannel Stereo?
max. number of processing (preamp) channels	11.2

Pure Direct
High Grade Audio Components?
Gold plated RCA terminals
Clock Jitter Reducer
Alpha Processing
Audyssey	MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume	/
Audyssey LFC
Audyssey APP support
Speaker Setup Presets	2

HEOS Multiroom & Streaming
Lossy formats MP3 / WMA / AAC	/ /
Lossless formats FLAC / ALAC / WAV	/ /
DSD Audio Streaming	up to DSD5.6
FLAC HD 192/24
WAV 192/24
ALAC 192/24
Gapless playback	(FLAC, WAV, ALAC, DSD)
AirPlay 2
Roon Tested
Internet Radio	TuneIn
Spotify Connect* / Tidal* / Deezer* / others *	/ / /
Amazon Prime Music* / Pandora*	/
Compatible with Remote APP for Smart Phones	Android / iOS/Amazon Kindle
Compatible with Remote APP for Tablets
Ethernet Ports
WiFi
Bluetooth
Bluetooth Headphone transmission

HDMI inputs back / front	7 / 1
HDCP2.3 support
HDMI outputs main / zone	2 / 1
HDMI max Resolution (8k / 4k)	8k/60 4k/120
Video conversion Analog -> HDMI
HDMI to HDMI scaling	up to 8K 60/50
HDMI: 8K / 4K / CEC / eARC	/ / /
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG	/ / /
HDMI: ALLM / QMS / QFT / VRR	/ / /
HDMI pass-though in standby mode
DSD Audio capability

HEOS Multiroom integrated
Multiroom zones	3
Main room multichanel audio - Zone stereo downmix
Zone audio source: HDMI / opt, coax / Network, USB / analog	(2ch) / (2ch) / /
Zone audio output: speaker / preout	/
Zone HDMI output from HDMI source
Webbrowser Setup
IP control / RS232 control / Web control / App control	/ / /
Remote In / Out
DC Trigger output	2

Voice Control - Works with Amazon Alexa
Voice Control - Google Assist / Apple Siri	/
Voice Control - Microphone built-in
Auto speaker setup by microphone	Audyssey MultEQ XT32
FL Display	2 lines + port hole
Graphic User Interface - GUI	Advanced
ISF certification
GUI languages	9
Setup Assistent
Firmware Update by Network / USB	/
Variable cross over
Optimized Bass Redirection
Bass Sync
Auto Power off
Sleep Timer

Composite In / Out	3+1 / 2
Component In / Out	3 / 1
HDMI In / Out	7+1 / 3
Multi-Room Video Out: Video / HDMI	/
Analogue In / Out	6+1 /
Phono (MM) In
Digital in: optical / coaxial	2 / 2
Multi-Room Out: analog / digital	2 /
Multichannel Pre Out	(11.2 RCA & 11.2 XLR)
Subwoofer Out	2 (independant)
7.1 multichannel input
Speaker A / B	assignable pre out
Bi-amp drive	assignable pre out
Multi-Room Speaker Terminal	pre out
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB	/ / / /
USB Audio (Front) / Made for iPod / Made for iPhone	/ AirPlay / AirPlay

Pre-programmed / Learnable / LCD Display	/ /
Power Consumption in W	60
Standby Consumption in W	0.2
CEC Standby Consumption in W	0.5
Network Control On Consumption in W	3.7
Maximum Dimensions<br/>Antenna:Horizontal:(W x D x H) in mm<br/>( Antenna:Vertical :(W x D x H) in mm)<br/>? w/o Antenna :(W x D x H) in mm?	440 x 411 x 185 ( 440 x 411 x 247 )  440 x 392 x 185
Weight in kg	10.4
Carton Maximum Dimensions (W x D x H) in mm	537 x 497 x 281
Carton Weight (inc. product) in kg	13.1
