Ο Pioneer VSX-LX505 ειναι home cinema ραδιοενισχυτης 11.2 καναλιων, 9 καναλιων ισχυος, εκαστο 120wrms (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven FTC) . Διαθετει: Internet Radio, FM, AM, DAB, DAB+. Ενσυρματη συνδεσιμοτητα εικονας 7x HDMI In, 2x HDMI Out. Ασυρματη διασυνδεσιμοτητα με WiFi, Bluetooth. Υποστηριζομενοι Codecs εικονας: HDR, HDR 10, Dolby Vision. Ηχου: Dolby Atmos, DTS:X.
Άμεση Διαθεσιμότητα
ΔΩΡΕΑΝ ΑΠΟΣΤΟΛΗ ΣΕ ΟΛΗ ΤΗΝ ΕΛΛΑΔΑ
Ο Pioneer VSX-LX505 ειναι home cinema ραδιοενισχυτης 11.2 καναλιων, 9 καναλιων ισχυος, εκαστο 120wrms (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven FTC) . Διαθετει: Internet Radio, FM, AM, DAB, DAB+. Ενσυρματη συνδεσιμοτητα εικονας 7x HDMI In, 2x HDMI Out. Ασυρματη διασυνδεσιμοτητα με WiFi, Bluetooth. Υποστηριζομενοι Codecs εικονας: HDR, HDR 10, Dolby Vision. Ηχου: Dolby Atmos, DTS:X.
Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.
The VSX-LX505 powers 9.2 dedicated channels with 120 watts per channel and has the processing power to up that to 11.2 channels with the addition of pre-amplifiers.
To ensure the best home entertainment experience possible, the VSX-LX505 is equipped with IMAX® Enhanced Audio and Dirac Live® Room Correction for a full home which adjusts sound according to the space and speakers while offering improved musical staging, dialog, and deeper bass. And you can go beyond a one room experience – the Pioneer VSX-LX505 brings cinema-quality sound and images to multiple rooms so you can have the premium experience in multiple rooms at once.
Features
IMAX Enhanced Mode
Experience powerful 4K HDR images and sound with IMAX digitally remastered content, just as the filmmaker intended. Pioneer's IMAX Enhanced Mode is meticulously optimized to play digitally remastered content to deliver the best viewing and listening experience on Earth.
Super Immersive Viewing
HDMI 2.1 supports a range of video resolutions including 8K60, 4K120 and Dynamic HDR. Combine that with 60Hz refresh rates for smooth and sharp playback, even for high-speed action.
All Encompassing Sound
With or without upfiring speakers, E-ARC (Enhanced Audio Return Channel) simplifies connectivity and supports the latest high-bitrate audio formats including Dolby Atmos®, DTS-HD Master Audio™, DTS:X® and Dolby TrueHD. Say hello to lifelike, object-oriented sound in smooth, curving movements or realistic overhead height effects.
Pristine Listening, Any Room
State-of-the-art Dirac Live room correction technology takes the room out of the equation and unlocks your loudspeakers’ full potential—no upgrade required. It automatically calibrates sound to the room using either a smartphone + the included wired mic or the Dirac Live PC/MacOS app + a 3rd party USB mic (not included). You’ll get a more accurate measurement of your surround sound positioning and more precise and balanced sound overall.
Auto Room Tuning
Pioneer’s Multi-Channel Acoustic Calibration System (MCACC) automatically adjusts sound according to your listening area and speakers by suppressing the standing waves that occur between walls or ceiling and the floor. Additionally, Auto Phase Control Plus makes real-time analysis of the phase difference and automatically compensates for the gap, resulting in strong bass and clear high-frequency sound.
Bi-Directional Bluetooth
Now, Bluetooth connectivity is even better with bi-directional Bluetooth. Stream from your device to the AVR using SBC or AAC codecs, or transmit audio playing through the AVR to compatible wireless headphones. This is great news if you want to stream from your phone or for the gamer in your life…or maybe for the person who doesn’t want to hear what their gamer is playing.
Streaming
With access to several streaming services like Works with Sonos, Chromecast built-in™, AirPlay 2, DTS Play-Fi®, Spotify®, Amazon Music, Pandora®, TIDAL, Deezer and TuneIn you won’t run out of music.
Roon Tested and Ready for You
Roon is capable of playing your entire music library to many devices, but Roon Tested devices like the VSX-LX505 are profiled by the Roon team to ensure simple setup and effortless daily use. You can be confident that you’ll enjoy the best musical experience.
Multi-room Entertainment
Wirelessly stream audio from any compatible mobile device to your AV Receiver and DTS Play-Fi compatible audio systems to create a multi-room system in your home. You can even stream different sources to different speakers at the same time from the DTS Play-Fi app.
Specifications
Channels | 9 |
Amplification Type | Direct Energy |
230 W/ch | 6 ohms, 1 kHz, THD 10 %, 1ch Driven |
120 W/ch | 8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven FTC |
IMAX Enhanced | Yes |
Dolby Atmos®, Dolby Surround Upmixer supports DTS Formats | Yes |
DTS:X®, DTS Neural:X® Upmixer supports Dolby Formats | Yes |
Reflex Optimizer | Yes |
Dolby Atmos Height Virtualizer | Yes |
Dolby® TrueHD, Dolby Digital Plus | Yes |
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express | Yes |
DSD Disc (SACD) Playback via HDMI | 2.8 MHz/2 ch, 5.1 ch |
Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus™ floating-point DSP (TI) | Yes |
Hi-Res Audio | 192 kHz/24-bit D/A Conversion |
Enhanced Audio Return Channel (eARC) on HDMI Out (Main) | Yes |
Advanced MCACC Auto Room Tuning | AutPhase Control Plus, Subwoofer EQ, Multi-point Standing Wave Control |
Dirac Live® Room Correction | Yes |
Advanced Sound Retriever (2ch) | Yes |
Advanced Surround Modes | Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Mono Music, Front Stage Surround Advance |
Support HDMI 2.1 with 8K | VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), QFT (Quick Frame transport), DSC (Display Stream Compression), and QMS (Quick Media Switching) pass-through |
Supports HDR10+, HDR10, and HLG; 8K/60p (4:2:0/10-bit), 8K/30p (4:4:4/10-bit, 4:2:2/12-bit), 4K/120p (4:4:4/10-bit, 4:2:2/12-bit), 4K60p (4:4:4/12-bit) and BT.2020 color; DeepColor™ (36-bit), “x.v.Color”, LipSync, and HDCP 2.3 | Yes |
Dolby Vision Compatible | Yes |
Ultra HD Upscaling | 4K to 8K, 1080p to 8K/4K |
Works with Alexa supporting multi-room music | Yes |
Works with Hey Google and Chromecast built-in | Yes |
DTS Play-Fi with Pioneer Music Control App*3 supporting Hi-Res Audio Playback | Yes |
Apple AirPlay 2 with Siri Voice Control | Yes |
Works with SONOS supporting multiple Sonos Connect control and Volume Pass Through mode | Yes |
Amazon Music HD, Pandora®, Spotify, TIDAL, and Deezer Hi-Fi Music-Streaming Services Ready | Yes |
Internet Radio with TuneIn | Yes |
Hi-Res Audio File Playback via USB/Network | Yes |
Up to 192 kHz/24-bit ALAC*6, AIFF, FLAC, WAV (RIFF) and 11.2 MHz DSD* | Yes |
Personal Preset | Yes |
Dialog Enhancement | Yes |
Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in | Yes |
Bluetooth® Wireless Technology | Transmitter/Receiver (Version: 4.2, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/aptX/aptX HD (TX), SBC/AAC(RX)) Built-in |
Pioneer Remote App | Ready for Multi-room Entertainment Control and Network Streaming |
User-Friendly GUI with System Setup Menu | Yes |
On-Screen Information for Audio, Video and Network | Yes |
Web Setup | Yes |
Auto Power Off in HDMI Standby Through | Yes |
AM/FM Tuner 40 Presets | Yes |
Sleep Timer | Yes |
User-Friendly Simple Remote Control | Yes |
HDMI 1 In | Yes |
USB 1 In for USB Drive | Yes |
MCACC/Dirac Live Setup MIC In | Yes |
Phones 1 Out (Gold-Plated) | Yes |
HDMI 6 In | 4 Assignable |
HDMI 2 Out | 1 for MAIN, 1 for SUB/ZONE 2 |
Ethernet | 1 In |
USB 1 In for USB Drive | Yes |
AV (Component) 1 IN | Assignable |
AV (Composite) 2 In | Assignable |
Audio 1 In | Assignable |
Phono (MM) 1 In | Yes |
Digital Coaxial 1 In | Assignable |
Digital Optical 1 In | Assignable |
FRONT, CENTER, SURROUND, SURROUND BACK, HEIGHT 1, HEIGHT 2, SUBWOOFER x 2 Pre Out | Yes |
ZONE 2 Pre/Line Out/ZONE B Line Out | Yes |
ZONE 3/HEIGHT 2 Pre/Line Out | Yes |
Speaker 11 channel Out | FRONT, CENTER, SURROUND, HEIGHT 1/Bi-AMP, SURROUND BACK/ZONE 3/HEIGHT 2, ZONE 2 |
IR 1 In | 1 Out |
12 V Trigger | 2 Out |
RS-232C | Yes |
FM/AM Antenna | Yes |
Power Requirements | AC 120 V, 60 Hz |
Power Consumption/Standby | 850 W/0.1 W |
Dimensions (W x H x D) | 17-1/8 x 7-5/16 x 15-3/16 inches (435 x 185 x 386 mm) |
Weight | 28.7 lbs. (13 kg) |
Carton Dimensions | 21-5/16 x 12-3/16 x 19-3/16 inches (541 x 310 x 487 mm) |
Carton Included Weight | 35.3 lbs. (16.0 kg) |
